DESCRIPTION

Basic Info

Model NO.	Rw5
Transport Package	Wooden Box
Specification	730*610*880
Trademark	RUNNINGWAY
Origin	Shanghai
HS Code	8414809090
Production Capacity	1000sets/Year

Product Description

What is a Scroll Compressor?
These two spirals from the heart of a scroll displacement compressor. One scroll is fixed, while the other rotates, driven by a motor.
Through its movement, the orbital scroll pulls in air from the outside and traps it in the air pockets between the two spirals.
The scroll keeps turning and compresses the air as it moves to the center, where it is ready for use.
A scroll compressor is extremely efficient. Because it contains few moving parts, it is also reliable quiet, and compact.
This makes it an ideal point-of-use compressor for a wide range of industries, from laboratories to dairy farming to railway.
In addition, a scroll compressor is always oil-free, offering sustainability and guaranteed clean air for applications with stringent quality standards, like food and beverage, pharmaceuticals and hospitals.
Product Description
Runningway oil-free scroll air compressor with culinary and beavery applications. Capacity ranges between 0.3 and 5.4 m3/min.

Certified Air Compressor
The products have passed the TUV Class 0, IP67, EMC, and salt spray tests in Germany.

No Oil
Oil-free, to entirely eliminate the problem of oil leaks and oil in compressed air.

0 Emissions
To achieve zero emissions, avoid using clean oil discharge and waste oil processing on a regular basis.

Efficient
Scrolling indefinitely, high efficiency, and low energy consumption

Low Cost
Maintenance is simple and time-consuming; preventive maintenance requires only 2 hours each year.

Low Failure Rate
The slip sheet machine has a low failure rate of less than 10%, there is no oil emulsification phenomenon, and maintenance is simple and convenient.

Low Noise
During operation, the dynamic and static scrolls do not come into touch, resulting in little vibration and noise.

Simple Structure
Scroll air end features a simple structure, fewer parts, and fewer worn parts, which considerably lowers the need for replacement parts while maintaining excellent durability. High-quality air supply capability and a sturdy structure design can improve reliability.
Product Parameters

Model	Air Flow	Pressure	Power	Noise	Motor Voltage	Dimension	Weight	Exhaust Outlet Diameter	Host Number
	m3/min	Mpa	KW	dB(A)	V/Hz/PH	(L*W*H)mm	Kg	Inch	Piece
Rw4-8	0.4/0.3	0.8/1.0	3.7	55±2	380/50/3	730*610*880	200	3/4	1A
Rw4-8T	0.4/0.3	0.8/1.0	3.7	55±2	380/50/3	1300*840*1480	300	3/4	1A
Rw4-8N	0.4/0.3	0.8/1.0	3.7	55±2	380/50/3	1400*900*1480	350	3/4	1A
Rw5-8	0.6/0.4	0.8/1.0	5.5	58±2	380/50/3	730*610*880	210	3/4	1B
Rw5-8T	0.6/0.4	0.8/1.0	5.5	58±2	380/50/3	1300*840*1480	310	3/4	1B
Rw5-8N	0.6/0.4	0.8/1.0	5.5	58±2	380/50/3	1400*900*1480	360	3/4	1B
Rw7-8	0.8/0.6	0.8/1.0	7.5	60±2	380/50/3	1170*700*1080	380	1''	2A
Rw7-8T	0.8/0.6	0.8/1.0	7.5	60±2	380/50/3	1755*840*1640	480	1''	2A
Rw7-8N	0.8/0.6	0.8/1.0	7.5	60±2	380/50/3	1700*800*1700	500	1''	2A
Rw11-8	1.2/0.8	0.8/1.0	11	62±2	380/50/3	1170*700*1080	400	1''	2B
Rw11-8T	1.2/0.8	0.8/1.0	11	62±2	380/50/3	1755*840*1640	500	1''	2B
Rw11-8N	1.2/0.8	0.8/1.0	11	62±2	380/50/3	1700*800*1700	550	1''	2B
Rw15-8	1.6/1.2	0.8/1.0	15	65±2	380/50/3	1100*700*1750	500	1''	4A
Rw16-8	1.8/1.5	0.8/1.0	16.5	65±2	380/50/3	1170*700*1550	600	1''	3B
Rw22-8	2.4/2.0	0.8/1.0	22	68±2	380/50/3	1550*1170*1075	800	1.5''	4B
Rw27-8	3.0/2.4	0.8/1.0	27.5	70±2	380/50/3	1550*1170*1550	1080	1.5''	5B
Rw33-8	3.6/3.0	0.8/1.0	33	70±2	380/50/3	1550*1170*1550	1200	1.5''	6B
Rw38-8	4.2/3.6	0.8/1.0	38.5	72±2	380/50/3	2150*1450*1580	1400	2.0''	7B
Rw44-8	4.8/4.0	0.8/1.0	44	72±2	380/50/3	2150*1450*1580	1500	2.0''	8B
Rw49-8	5.4/4.5	0.8/1.0	49.5	72±2	380/50/3	2150*1450*1580	1650	2.0''	9B
